GAMME ARCEAUX - C-ARMs
19Pages

RANGE PRESENTATION É7APELEM A BRAND OF DMS IMAGING

® Mobile imaging Systems ® Following applications: general surgery, orthopédie, pédiatrie, abdominal and neurosurgery, urology in combination with lithotripter, traumatology, digital subtraction angiography (DSA) ® High frequency pulsed generator associated with : O stationary anode (EVO+) : Microprocessor controlled high frequency generator 3,5 kW O rotating anode (EVO R+) : Microprocessor controlled high frequency generator 5 kW O rotating anode (EVO R+) : Microprocessor controlled high frequency generator 15 kW ® Enables all modes: continuous fluoroscopy, pulsed fluoroscopy and digital...

AT DMS L J IMAGING ® Main options : > Dose Area Product Meter (DAP) kit including chamber, electronics and display unit > Virtual collimation > Zéro dose digital rotation r Parallel Shutters

Mechanical Features for 9’’ II Free space 770 mm SID 980 mm rotating anode 988 mm fixed anode

Free space 720 mm Arm depth 690 mm

EYES Compact Performance

/I DMS L J IMAGING EVO+ / EVO R+ With memory EYES UNIT CONFIGURATION Monobloc : fixed or rotating anode I.I. Tube : 9" triple field CCD camera: 1 x 1 k Memory: Eyes Monitor: 24" color (on the trolley) 24" touch screen color (on the C-arm for compact version) Standard equipment: CD/DVD reader (not for compact) USB port (bmp export DICOM opt.) Ethernet port (DICOM) C-arm latéral handlers Cassette holder: 24 x 30 Options: printer Sony : UP971 or UP991 All DICOM modalities (NO DSA) DICOM WI-FI USB DAP and DAP printer Laser (on I.I. side) Stérile drapes set

The unit configured with EYES allows:  Electronic image rotation at 1°, recursive filters.  Image post processing elaboration (H/V image flip; customizable post processing LUT; b/w inversion; electronic shutters; spatial filters; digital magnification; image annotations and measures like stenosis %)  Pulsed Fluoroscopy Rates: 12 i/s, 6 i/s, 3 i/s, 1 i/s.  Dedicated APR curve to allow Continuous Fluoro up to 15 mA for sturdy patient (only for rotating anode).  Patient Database, Patient Data end exam type.  Storage capacity max. 55.000 images 1k x 1k.  Virtual collimators on LIH.  All...

/I DMS L J IMAGING EVO+ / EVO R+ With memory RTP 1000 UNIT CONFIGURATION Monoblock : fixed or rotating anode I.I. Tube : 9" triple field CCD: camera: 1 x 1 k Memory: RTP1000 Monitor : 19" B/W Standard equipment: CD/DVD reader USB port (bmp export DICOM opt.) Remote infrared controller Ethernet port (DICOM) DSA Cassette holder: 24 x 30 C-arm latéral handlers Options: printer Sony : UP971 or UP991 All DICOM modalities DICOM wireless module DAP and DAP printer Laser (on I.I. side) Stérile drapes set

The unit configured with RTP 1000 allows:  DSA with automatic and manual mask, road mapping, cineloop, digital image rotation with angle displayed, recursive filters.  Image post processing elaboration (H/V image flip; customizable post processing LUT; b/w inversion; electronic shutters; spatial filters; digital magnification; image annotations and measures like stenosis %)  Pulsed Fluoroscopy Rates: 2 i/s, 1 i/s, 1 i/3s.  Dedicated APR curve to allows Continuous Fluoro up to 15 mA for sturdy patient (rotating anode only).  Auto image storing every: 1/3/6/12/25 fps.  Patient Database,...

UNIT CONFIGURATION EVO R+With memory HRP 3000 Monoblock : rotating anode I.I. Tube : 9" triple field CCD: camera: 1 x 1 k Memory: HRP3000 Monitor : 19" B\W Standard equipment: CD/DVD reader USB port (bmp export DICOM opt.) Remote infrared controller Ethernet port (DICOM) DICOM Store, CD/DVD writer DSA Cassette holder: 24 x 30 C-arm latéral handlers Options: printer Sony : UP971 or UP991 All DICOM modalities DICOM wireless module DAP and DAP printer Laser (on I.I. side) Cassette holder: 18 x 24 - 24 x 30 - 10"x12" Stérile drapes set

The unit configured with HRP 3000 allows:  DSA with automatic and manual mask, road mapping, cineloop, digital image rotation with angle displayed, recursive filters.  Image post processing elaboration (H/V image flip; customizable post processing LUT; b/w inversion; electronic shutters; spatial filters; digital magnification; image annotations and measures like stenosis %,…)  HCF pulsed fluoroscopy rates : 1/3/6/12/25 fps @ 15/30 mA  HCF-DSA with auto store : 0.5/1/2/3/4/6/12/25 fps @ up to 60 mA  Auto image storing every: 1 / 3 / 6 / 12 / 25 fps  Patient Database, Patient Data end...

EVO R+ 15 With memory HRP 3000 unit configuration Monoblock : rotating anode Monobloc Water cooled! I.I. Tube : 9" or 12" triple field CCD: camera: 1 x 1 k Memory: HRP3000 Monitor : 19" B\W Standard equipment: CD/DVD reader USB port (bmp export DICOM opt.) Remote infrared controller Ethernet port (DICOM) DICOM Store, CD/DVD writer DSA C-arm latéral handlers Cassette holder: 24 x 30 Options: printer Sony : UP971 or UP991 All DICOM modalities DICOM wireless module DAP and DAP printer Laser (on I.I. side) Stérile drapes set

The 15 kW unit configured with HRP_NW allows:  DSA with automatic and manual mask, road mapping, cineloop, digital image rotation with angle displayed, recursive filters.  -Image post processing elaboration (H/V image flip; customizable post processing LUT; b/w inversion; electronic shutters; spatial filters; digital magnification; image annotations and measures like stenosis %,…)  HCF pulsed fluoroscopy rates : 1/3/6/12/25 fps @ 15/30 mA  HCF-DSA with auto store : 0.5/1/2/3/4/6/12/25 fps @ up to 150 mA  Auto image storing every: 1 / 3 / 6 / 12 / 25 fps  Patient Database, Patient Data...

Intended use Traumatology Orthopedics Pacemaker implantation Peripheral Angiography Digestive system Generic Surgery Biliary drainage and stenting Image guided biopsy

/■n DMS L/ IMAGING Main Applications and suggested Memories S Are you going to do any exam with Contrast Media? (HCF/DSA with acquisition required) S Prevalent Body Region and duration of the exam? (Fixed/Rotating Anode and Memory) S Resolution expected by the images? (CCD, Monitor, Memory) S Only as an example, here below are listed some «suggested applications» accordingly to the Memory type: -EYES: Orthopaedics, Pacemaker, Litotripsy. -RTP 1000 and HRP 3000: pacemaker, endoscopy, biopsy , endovascular surgery, Peripheral angiography. -HRP 3000 advantages: higher mA values than RTP1000.
